Charakteristische Vorteile
High stability, rigidity, and tensile strength to prevent cutting or destroying.
Anti-acid and alkali.
Harsh environment resistance.
Corrosion and rust resistance.
Available to combine with other fences for high level security barrier.
Convenient installation.Easy to maintain.
Durable and long service life. -
Gemeinsame Spezifikationen
Barbed Wire Specifications
Typ
Wire Gauge (SWG)
Barb Distance (cm)
Barb Length (cm)
Electro Galvanized Barbed Wire; Hot-dip zinc plating barbed wire
10# x 12#
7.5-15
1.5-3
12# x 12#
12# x 14#
14# x 14#
14# x 16#
16# x 16#
16# x 18#
PVC coated barbed wire; PE barbed wire
before coating
after coating
7.5-15
1.5-3
1.0mm-3.5mm
1.4mm-4.0mm
BWG11#-20#
BWG8#-17#
SWG11#-20#
SWG8#-17#
Note: PVC PE coating thickness: 0.4mm-0.6mm; different colors or length are available at customers request.
-
Anwendungsbereich
1. Boundary protection and isolation
The barbed wire was originally designed to prevent intrusion and illegal crossing of boundaries, and is widely used in various border security isolation systems:
National border: Used in conjunction with fences, walls, etc. along the border to prevent illegal intrusion.
Military restricted areas/outposts: Enhance the defense strength of military areas to prevent personnel from approaching.
Prisons and detention centers: Install spiral barbed ropes on the top to prevent climbing and escaping.
Airports/power plants/reservoirs: Security reinforcement should be carried out around important facility areas to prevent illegal intrusion.
2. Construction site/temporary area security
Construction site: Surrounded by temporary walls to prevent theft or personnel from entering.
Large scale event security: For crowd control areas such as concerts and marathons, use barbed wire to isolate and seal them off.
Epidemic isolation zone: Temporary isolation zones are set up during special periods.
3. Agricultural and Pastoral Use
Breeding fence: Install barbed ropes on the fence to prevent livestock from escaping, such as cows, sheep, horses, etc.
Preventing Beast Invasion: Install barbed ropes around forest farms or orchards to prevent wild animals such as wild boars and dogs from entering.
Top protection of chicken coop and duck shed: prevent raptors from diving and hunting.
4. Industrial and warehouse security
Top protection of factory exterior walls: Enhance the perimeter security of industrial parks.
Warehouse and open-air material yard: prevent theft and intrusion.
Surrounding mining areas and oil fields: isolate safe areas from work areas.
5. Protection of Homestead and Private Property
Above the perimeter walls of villas/estates: Increase the level of security measures.
Surrounding walls of villages and towns: a low-cost and easy to maintain safety protection method.
Vacant property/land blockade: Stabbing ropes facilitates quick blockade of open spaces or unused building areas.
6. Combined use with other facilities
Installation with Y-shaped columns and T-shaped steel columns: commonly used in military/prison applications.
Combined installation with wire mesh and blade barbed wire: enhances protection level.
Installed on top of wrought iron guardrails and steel structure guardrails: as an additional protective layer. -
