Characteristic advantages
- Excellent corrosion resistance, particularly resistant to seawater, saltwater, hydrofluoric acid, and alkaline environments.
High strength and toughness are more resistant to impact and wear than ordinary stainless steel.
High temperature resistant and capable of withstanding working environments up to 480 ° C (900 ° F).
Strong antioxidant properties, able to maintain stability even in oxidizing and reducing environments.
Non magnetism is usually non-magnetic in the annealed state.
-
Common Specifications
The commonly used specifications are
Monel 400（UNS N04400）， High strength, resistant to hydrofluoric acid and seawater corrosion
Monel K500 (UNS N05500), an enhanced version of Monel 400 with higher mechanical performance
Mesh Count
Wire Diameter (mm / inch)
Aperture Size (mm / inch)
Weave Type
Typical Applications
10 mesh
0.60 mm / 0.0236"
1.94 mm / 0.0764"
Plain Weave
Seawater filtration, protective mesh
20 mesh
0.50 mm / 0.0197"
0.77 mm / 0.0303"
Plain Weave
Medium particle screening
40 mesh
0.28 mm / 0.0110"
0.36 mm / 0.0142"
Plain Weave
Liquid/gas filtration
60 mesh
0.18 mm / 0.0071"
0.24 mm / 0.0094"
Twill Weave
Precision filtration, lab use
80 mesh
0.15 mm / 0.0059"
0.17 mm / 0.0067"
Plain Weave
Corrosive fluid filtration
100 mesh
0.10 mm / 0.0039"
0.15 mm / 0.0059"
Plain / Twill
Chemical filtration
150 mesh
0.07 mm / 0.0028"
0.10 mm / 0.0039"
Twill Weave
Fine powder filtration
200 mesh
0.05 mm / 0.0020"
0.08 mm / 0.0031"
Twill Weave
Ultra-fine gas and liquid filtration
-
Application Area
Marine equipment: inlet filter, pump protection net
Chemical industry: filtration of highly corrosive media (such as acid-base and salt solutions)
Aerospace: High temperature and high pressure filtration systems
Medicine and food: filtration applications with high safety requirements
Laboratory/Research: Precision filtration, reaction control
-
