Characteristic Advantages
- Corrosion resistance can be used for a long time in extreme environments such as sulfuric acid, seawater, phosphoric acid, hydrochloric acid, etc
- High strength and toughness, good ductility, and not easily broken
- High temperature resistance performance. The working temperature can reach over 450 ° C
- Good weldability can be used to maintain corrosion resistance even after fine structure welding
- Long service life suitable for long-term deployment in harsh environments
-
Common Specifications
Mesh（目数）
Wire Diameter (mm / inch)
Aperture (mm / inch)
Open Area (%)
Weave Type
Typical Use
10 × 10
0.6 mm / 0.0236"
1.94 mm / 0.0764"
~60%
Plain Weave
Mechanical screening
20 × 20
0.4 mm / 0.0157"
0.87 mm / 0.0343"
~50%
Plain Weave
Liquid filtration, safety mesh
30 × 30
0.3 mm / 0.0118"
0.54 mm / 0.0213"
~46%
Plain Weave
Chemical filtration
50 × 50
0.2 mm / 0.0079"
0.31 mm / 0.0122"
~37%
Plain Weave
Fine filtration
80 × 80
0.14 mm / 0.0055"
0.18 mm / 0.0071"
~32%
Twill Weave
Gas / oil filtration
100 × 100
0.112 mm / 0.0044"
0.14 mm / 0.0055"
~30%
Twill Weave
Precision screening
150 × 150
0.071 mm / 0.0028"
0.098 mm / 0.0038"
~28%
Twill Weave
Liquid microfiltration
200 × 200
0.05 mm / 0.0020"
0.077 mm / 0.0030"
~25%
Twill / Dutch
High precision filters
325 × 2300
0.035 / 0.025 mm / 0.0014" / 0.0010"
N/A (Dutch Weave)
Low (<10%)
Reverse Dutch Weave
Acid & gas ultra-fine filtration
-
Application Area
Petrochemical equipment filtration
seawater desalination system
Paper making, dyeing and finishing industry
Battery manufacturing and acidic liquid treatment
Pharmaceutical and Food Industry
High end environmental protection filtration equipment
-
